HUMAN MODELS
LOUIS











Louis



General Information

Sex male
Type teenager
Age [Years]
14
Height [m]¹
1.68
Weight [kg]
49.7
BMI [kg/m²] 17.6

¹ Height, Weight, and BMI are for V3.x









Version History

Version Specifications Download
cV3.1

Louis cV3.1 is based on the geometry of V3.0 and is ready for the new biomechanics-based FEM Poser in Sim4Life. The new poser treats the body as a hyperelastic material with rigid bones and provides more realistic posing compared to the previous approach. The tissue list has been updated and includes individual bones in the feet.

DOI: 10.13099/VIP11006-03-1
V3.0

Louis V3.0 includes 306 tissues and is based on a resegmentation of V1.3 at higher resolution, a more consistent tissue assignment, enhanced surface processing, and anatomical refinements. Met requirements for unstructured mesh generation are: non-degenerate triangles, smooth surface patches, and water-tight, topologically conforming surfaces. V3.0 presents a limited number of self-interesections. Material assignment is possible using the properties database v2.5 or higher.

DOI: 10.13099/ViP-Louis-V3.0
V1.3 Louis V1.3 includes 182 tissues segmented from MRI data. The surfaces have been extracted and processed to generate topologically compatible, gap-free tissue geometries. Tissue properties can be assigned based on any version of the properties database.
Height: 1.68 m
Weight: 50.4 kg
BMI: 17.7 kg/m²
DOI: 10.13099/ViP-Louis-V1.3
