DUKE









Duke



General Information

Sex male
Type young adult
Age [Years]
34
Height [m]¹
1.77
Weight [kg]
70.2
BMI [kg/m²] 22.4

¹ Height, Weight, and BMI are for V3.x









Version History

Version Specifications Download
cV3.1.1

Duke cV3.1.1 is an update release fixing some small issues in the skin of cV3.1. This version has an updated tissue list with separated bones in the toes.

DOI: 10.13099/VIP11001-03-1-1
cV3.1

Duke cV3.1 is based on the geometry of V3.0 and is ready for the new physics-based Poser in Sim4Life. The FEM-based poser provides more realistic posing compared to version cV3.0, with some additional posable joints and a wider range of applicability.

DOI: 10.13099/VIP11001-03-1
cV3.0.1

Duke cV3.0.1 offers improved posing functionality as compared to cV3.0 for specific postures.

DOI: 10.13099/VIP11001-03-01
cV3.0

Duke cV3.0 offers posing functionality. It has been generated based on V3.0 by positioning pivot points to define centers of rotation in the joints and by assigning influence regions. These regions identify the body areas that are affected by the movement of associated bones and their degree of deformation.

DOI: 10.13099/VIP11001-03-0
V3.0

Duke V3.0 includes 305 tissues and is based on a resegmentation of V1.3 at higher resolution, a more consistent tissue assignment, enhanced surface processing, and anatomical refinements. Met requirements for unstructured mesh generation are: non-degenerate triangles, smooth surface patches, and water-tight, topologically conforming surfaces. V3.0 presents a limited number of self-interesections. Material assignment is possible using the properties database v2.5 or higher.

DOI: 10.13099/ViP-Duke-V3.0
V1.3 Duke V1.3 includes 146 tissues segmented from MRI data. The surfaces have been extracted and processed to generate topologically compatible, gap-free tissue geometries. Tissue properties can be assigned based on any version of the properties database.
Height: 1.77 m
Weight: 72.4 kg
BMI: 23.1 kg/m²
DOI: 10.13099/ViP-Duke-V1.3
