HUMAN MODELS
Fats BMI 29











Fats BMI 29



General Information

Sex male
Type1 overweight adult
Age [Years] 37
Height [m] 1.82
Weight [kg] 96
BMI [kg/m²] 29

1According to the BMI classification by the WHO





Version History

Version Specifications Download
mV3.1

This model is based on Fats V3.1  morphed to a BMI of 29 kg/m² using a realistic physics-based morphing approach, which shrinks (or expands) specific tissues. The morphing is performed using a bio-mechanical solver with hyper-elastic soft tissues and rigid bones. Local shrinking (or expansion) is modeled using a thermal expansion analogy. The same tissues  as in the original model are included.

DOI: 10.13099/VIP11014-03-W96H182
